Samsung QM43B-T Signage Touch 43 inch

Certification and Compliance

EMC

Class B

Safety

60950-1 / 62368-1
Display

Screen Size

43"

Resolution

3,840 x 2,160

Brightness

500 nit (without Glass)

Contrast Ratio (Dynamic)

Mega

Viewing Angle (H/V)

178/178

Response Time

8ms

Panel Type

VA

Pixel Pitch (HxV)

0.245 x 0.245 (mm)

Brightness (Typical)

500(without Glass), 400(with Glass) nit

Color Gamut

92% (DCI-P3, CIE 1976) %

Glass Haze

25% %

H-Scanning Frequency

30 ~ 81kHz

Maximum Pixel Frequency

594MHz

V-Scanning Frequency

48 ~ 75Hz

Operation Time Support

24/7
Connectivity

HDMI In

3

DP In

1

USB

2

IR In

Yes

Audio Out

Stereo Mini Jack

RS232 In

Yes

RS232 Out

Yes

RJ45 In

Yes

Wi-Fi

Yes

Bluetooth®

Yes

Version of HDMI

2

Version of HDCP

2.2

Verison of DP

1.2
Power

Power Supply

AC 100 - 240 V, 50/60 Hz

Power Consumption (On Mode)

110W W

Power Consumption (Sleep Mode)

0.5W W

Typical[W/h]

90

Max[W/h]

110
Features

Key

UHD Signage with Built-in MagicInfo S10, SSSP 10.0

S/W

Workspace (Microsoft365/VMWare/RDP) Custom Home Auto Source Switching & Recovery Dicom Simulation Mode Director Mode Upgradable Web-Engine Tizen Enterprise Platform Video Conference Solution [end of June~] Smart Calibration

H/W

Symmetric Design (same with QxR) Center IR Temperature Sensor Auto Level Wi-Fi(2.4/5.0GHz dual) & BT

Touchscreen

Yes
Touch

General Feature

VA

Touch Technology

Capative
Internal Player

Processor

Cortex A72 1.7GHz Quad-Core CPU

Storage

16 GB

Operating System

Tizen 6.5
Dimensions

Packaging (W x H x D)

1134 x 725 x 141

Package Dimensions (W x H x D)

1134 x 725 x 141 mm
Weight

Package Weight

18.7

Set Weight

14.5
Accessories

Included in Box

Quick Setup Guide, Warranty Card, Power Cord RS232C(IN) Gender Remote Controller & Batteries

Stand

STN-L4355G

Mount

WMN4070SG (Land Only) WMN750ME

Specialty

CML400XR
Mechanical Specs

VESA Mount

200 X 200

Bezel Width (mm)

26.0/26.0/21.0/21.0 (U/D/L/R)
Operation Conditions

Temperature

0?~ 40?

Humidity

10~80%
Mechanical Specification

VESA Mount

200 x 200 mm

Frame Material

Non-Glossy
Optional Feature

Touch

Yes

Mount

WMN4070SG

Stand

STN-L4355G
SoC

OS Version

Tizen 6.5

Flash Memory Size

16GB
Certification and Compliance

Environment

ENERGY STAR 8.0, EPEAT

IP Rating

IP5x

Security

802.1x(WPA2 Enterprise) : EAP-TLS, EAP-TTLS, EAP-PEAP
Display Panel

Class

43

Measured

42.5" / 107.9cm

Resolution

3840x2160(16:9)

Orientation

Landscape / Portrait

Haze

25% (without Glass)

Contrast Ratio (Typ)

4000:1 (* IPS - 1200:1)

General Feature

VA

Active Display Area

941.184 (H) x 529.416 (V)

Pixel Pitch (mm)

0.2451 x 0.2451

Brightness (Typ.)

500 nit (without Glass)

Color Gamut

92% (DCI-P3, CIE 1976)
Connectivity / Sounds

Video

DP 1.2 (1), HDMI 2.0 (3)

USB

USB 2.0 x 2

HDCP

HDCP2.2

USB

Touch out 2 (PC/screen)

Audio

Stereo mini Jack

External Control

RS232C(in/out), RJ45

Speaker

10W 2ch
